Supported floors: 8 floors, expandable to 48 floors and 64 floors.
Standard voltage DC9V-DC30 (±30%)
Working current <1000mA;
Working temperature -40℃～85℃
Working humidity <90%
Number of floors Main control board: 16.24.32
Output load Photoelectric drive
User capacity 10,000 can be expanded to 60,000
User password 10,000 groups
Record capacity 100,000
Communication method TCP/IP
Communication distance 100 meters
Number of networked units 100,000 units
Dimensions Mainboard: 160mm long x 100mm wide x 15mm high;
Adopts advanced ARM hook design with stable performance
Adopts network authorization and can be used offline or online
Can be directly connected to the cloud platform, and authorize cards,
fingerprints, and passwords through the cloud platform
Can support both key and direct functions
Support USB data export and import functions for easy data extraction.
The main board supports 32-layer management, and up to 64 layers
with expansion boards.
The main control board and the computer use TCP communication,
which is stable and reliable.
Supports 64 floor timing tasks
Supports 31 time period control
standard delivery
